Application
FG-104G series tablet hardness tester is a digital display tablet hardness tester designed and developed by our company. It has the advantages of high precision, easy operation and convenient carrying. The scientific use test range is 10%-100% of the full scale. The metrology department recommends not to use less than 1% of the full scale. At the same time, after the instrument and the object to be tested are in place before the test,
press the ZERO(ZERO) key to clear the ZERO to eliminate the weight of the fixture.
Features
* High precision and high resolution.
* Digital display, ignore the difference. * N(Newton), kg(kg), 1B (pounds), g(grams) four measuring units for choice, mutual conversion.
* Peak hold function. Maintain peak display until manually reset.
* Green environmental protection, can be set 10 minutes no operation automatic shutdown; It can also be manually shut down.
* Can be powered by alkaline batteries; Can also be connected to 5V DC power supply.
Specifications
Test scope | 0Kgf-20Kgf,0N-196N,0F-4426F |
| The resolution | 0.01Kgf,0.1N,0.0126F |
| Diameter of the test range | 15mm |
Precision | Plus or minus 0.5% FS (range) + 1 digital peak |
Unit | kgf, gf, N, Lbf |
Can be measured value | Peak, instantaneous value |
According to | Four big liquid crystal, the direction, double screen |
| Shutdown mode | Close automatically or manually shut down 10 minutes |
| Backlight | backlight |
| Allow the load | 150% F.s (super 110% E.s, beeping alarm). |
| The power supply | Section 2 battery 5 or 5 v dc power supply |
| Working temperature | 0°C~40°C |
| Working humidity | <80% |
| The work environment | Around the source and the corrosive medium |
| Turnning | 390g |
| Size | 211mmx80mmx36mm |
